TC-40EA-US

Technical Parameters

  • Product Model: TC-40EA-US

  • Certifications: ETL, ETL Sanitation, FCC, UL certified; meets NSF/ANSI STD.4 requirements

  • Heat Source Type: Electromagnetic

  • Input Voltage: 208V 60Hz AC 3P+N

  • Rated Power: 12kW

  • Input Water Pressure: 20-125 psi /0.14~0.86Mpa; Flow rate ≤1.8GPM

  • Water inlet: 1/2-14NPT internal thread

  • Cooking capacity: Optimal cooking capacity: 2Kg; Maximum stir-fry cooking capacity: 4Kg

  • Cooking time: Approximately 3-5 minutes/batch (serves 60-80 people/hour)

  • Pot type: Stainless steel

  • Product dimensions: W1000xD1025xH1780mm 39"X40"X70"

  • Net weight: 235kg/518lb (actual weight may vary)

  • Seasoning options: 1 channel water, 1 channel cooking oil, 1 channel cornstarch slurry, 1 channel sauce, 4 channels custom powder, 6 channels custom liquid seasoning
